Product Features
1. 8 * 3.5 "/2.5" SATA hard drive slots
2. Having a large storage capacity and supporting RAID 0, 1, 5 and other levels of storage devices, it can effectively protect user data from loss;
3. Stable platform design to minimize deployment costs to the greatest extent possible
4. Powerful scalability, support for multi bit flexible configuration of processors and memory storage
5. Support hot swappable hard drives, quick replacement, stable operation
6. Adopting a 550W 1+1 redundant power supply design to ensure stable power supply
Specification parameters1. 8 * 3.5 "/2.5" SATA hard drive slots
2. Having a large storage capacity and supporting RAID 0, 1, 5 and other levels of storage devices, it can effectively protect user data from loss;
3. Stable platform design to minimize deployment costs to the greatest extent possible
4. Powerful scalability, support for multi bit flexible configuration of processors and memory storage
5. Support hot swappable hard drives, quick replacement, stable operation
6. Adopting a 550W 1+1 redundant power supply design to ensure stable power supply
1. Processor: Supports dual CPUs, standard configuration includes 1 Intel Xeon Gold 6130, 16 cores and 32 threads, 2.1GHz
2. Chipset: Intel ® C621
3. Memory: 32GB DDR4
4. Memory slots: 8 memory slots
5. Expansion slot:
Total number of slots: three
2 PCIe 3.0 x16,
3 PCIe 3.0 x8,
1 PCIe 3.0 x4 (inx8 slot)
6. System disk: 2 * 120G SSD
7 USB： 4 USB 2.0 ports (2 through connector; 2 rear ports) 3 USB 3.2 Gen1 ports (2 through connector; 1 Type A)
8. Network: 2 RJ45 Gigabit Ethernet LAN ports
9. Image output: VGA port * 1
10 RAID： Features supporting storage devices at RAID0, 1, 5 levels
11. Graphic: 1 ASPEED AST2500 BMC Port
12. Fan specifications: 3 fans
13. Power supply: 550W redundant power supply
14. Size (mm): 650 * 437.5 * 88
15. Working temperature: 0 ℃~40 ℃
16. Non working humidity: 20%~90% (no condensation)
