1、5-megapixel Sony 335 sensor for clearer monitoring
2、Exceeding the same level of night vision effect, the effective distance can reach up to 150M
3、Supports 18x optical zoom and full range focusing
4、Standard P2P cloud monitoring
5、Supports H.265/MJPEG dual compression, triple stream;
6、Excellent stream control, low stream high image quality, latency less than 200ms
7、Dual system backup, fault self recovery, supporting A-B, cruise control and other functions;
8、Supports 6KV lightning surge protection and robust hardware
9、PWM infrared dimming technology ensures uniform brightness, low heat generation, and extends the service life of infrared lamps by more than three times;
Specification parameters:
1、Sensor type: Sony 335 sensor
2、Resolution: 2560 * 1920
3、Optical zoom: 18
4、Ball machine rotation range: Horizontal: 360 º Vertical: 93 º
5、Horizontal rotation speed: 0-120 °/s
6、Vertical rotation speed: 0-60 °/s
7、Auto Flip Function: Supports
8、Proportional transmission: automatic matching of speed and focal length
9、Infrared lights: 6/high-power dot matrix infrared lights; 2 laser lights, effective distance of 150M
10、Automatic control of infrared lamp: intelligent matching focal length PWM dimming technology
11、AB two-point scanning position: arbitrarily set
12、AB two-point scanning speed: 1-9 levels of speed can be set
13、Number of preset positions: 256
14、Number of inspection teams: 3 groups (each group has 16 independently editable stopping positions, stopping times, and speeds)
15、Mechanical zero calibration: supported
16、Multi stream: supports dual encoding and triple stream
17、Image compression: H.264/H.265/M-JPEG
18、Audio compression: G711，PCM
19、Network protocol: TCP/IP，HTTP， NTP，IGMP， DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS，PPPoE，P2P
20、Network security: HTTPS，802.1X、IP ADDRESS FILTERING
21、Network interface: 1-channel 10/100BaseT Ethernet, RJ45 interface
22、Quick command: PELCO instruction set
23、Waterproof grade: IP66
24、Power supply: DC12V/4A
25、Working temperature range: -10 ℃ to+50 ℃
26、Power consumption: ≤ 25W
