1. Adopt high-performance 4-megapixel 1/1.8" CMOS image sensor with high definition, starlight-level low illumination, high frame rate and good color reproduction;
2. Supports maximum 2560*1440@30fps high-definition picture output and three-stream technology. Each stream can be independently configured with resolution and frame rate;
3. Support H.264, H.265, and adaptive (SVC) encoding formats, suitable for different bandwidth and storage environments;
4. Support wide dynamic range, 3D noise reduction, strong light suppression, electronic shutter, digital watermark and other functions to adapt to different monitoring environments;
5. Built-in high-efficiency white light fill light, low power consumption, can perform face capture and recognition normally at night;
6. Support Micro SD/SDHC/SDXC card storage, up to 256G, support network disconnection and resume function to ensure that the video is not lost;
7. Support multiple anomaly detection, including motion detection, occlusion detection, storage anomaly, low storage space, network disconnection, IP conflict, MAC conflict, and illegal access;
8. Support DC12V/AC24V±20% power supply mode and wide voltage design;
9. IP67 protection level, surge protection, anti-static and lightning protection design;
Product parameters
1. Sensor type: 1/1.8", Progressive Scan CMOS
2. Minimum illumination: 0.001Lux (color); 0.0001Lux (black and white)
3. Electronic shutter: 1/50-1/100,000 seconds
4. Wide dynamic range: ≥120dB
5. Fill light: 4 white lights with intelligent fill light and adjustable brightness
6. HD lens: Electric zoom lens 3.6-10mm
7. Intelligent functions: face detection, face tracking, face selection, face attributes, face recognition, face exposure, face enhancement
8. Face capture performance: detect up to 30 faces at the same time, the minimum and maximum pixels for face detection can be set, and the detection area can be set
9. Face capture mode: optimal mode, automatic mode, monitoring mode, the number of captures and time can be set
10. Face attribute analysis: age, gender, mask, glasses, expression, etc.
11. Face recognition efficiency: recognition accuracy ≥ 99.50%, recognition speed ≤ 0.2S
12. Face database management: Maximum 30,000 face databases, storage of 100,000 comparison records
13. Blacklist and whitelist: support blacklist and whitelist comparison, blacklist alarm
14. Image coding standards: H.264B, H.264M, H.264H, H.265, MJPEG, SVC
15. Output bit rate: Video bit rate: 256Kbps～16384Kbps, Picture bit rate: 50KB～1024KB
16. Audio encoding: Audio compression standard: G711a, G711Mu, PCM; Audio sampling rate: 16KHz
17. Maximum resolution: 400W (2560*1440)
18. Resolution and frame rate:
Main stream 50Hz: 25fps (2560×1440, 1920×1080, 1280×720), 60Hz: 30fps (2560×1440, 1920×1080, 1280×720);
Auxiliary stream 1: 50Hz: 25fps (1280×720, 704×576, 352×288); 60Hz: 30fps (1280×720, 704×576, 352×288);
Auxiliary stream 2: 50Hz: 25fps (1280 × 720, 704 × 576); 60Hz: 30fps (1280 × 720, 704 × 576);19. OSD information overlay: picture and image OSD settings, name, date, week, address, font, coordinates, etc.
20. Region of interest: Face ROI enhancement, support setting 4 regions
21. Network protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, QoS, IPv6
22. Intelligent alarm: image occlusion, motion detection, network cable disconnection, IP address conflict, MAC conflict, storage abnormality
23. Video recording: manual recording; alarm recording; timed recording; motion detection recording; face detection recording; face recognition recording
24. Communication interface: 1 10/100M adaptive Ethernet port
25. Local storage: Support Micro SD/SDHC/SDXC card (up to 256G), support network disconnection and continuous download
26. Other interfaces: Alarm 1 input 1 output, audio 1 input 1 output, 1 channel 485 interface
27. Working environment: -30℃~60℃, humidity less than 95% (no condensation)
28. Equipment power supply: Power supply: AC24V/DC12V±20%, power consumption ≤5W (fill light is not turned on)
29. Protection level: IP67 protection level, surge protection, anti-static, lightning protection design
30. Dimensions (mm): 227 (L) * 106 (W) * 100 (H) (excluding antenna)
